[TC27] Lowrider
Zerobricks posted a topic in LEGO Technic, Mindstorms, Model Team and Scale Modeling
Here's my entry for the TC27 - the physical model is also completed and tested, but I'm stil waiting for the 2x C frames (3167) to arrive (for testing purpose I just 3D printed my own pieces ). Anyway, I wanted to build something unique and different this time around. I've been thinking of building a motorized lowrider for a while now and this challenge was the perfect excuse to realize it. With this model I wanted to realize the following functions: Motorized suspension Steering mechanism connected to the steering wheel Working fake engine driven by rear wheels Openable (suicide) doors, hood and boot Proper, clean and spacious interior Along with those functions I also managed to squeeze one more additional function, which makes the car a convertable. Here's the end (digital) result: So as you can see, it actually uses the correct tires and rims which I think is a good start! Here's how it looks like all opened up - notice the inline 4 fake engine: Here's a look from the rear, showcasing the large rear typical of lowriders, which is also used to house the two BuWizz 2.0 bricks. I took great care to give the model some fins, proper brick-built lights, bumper, exhausts, etc... Looking at the underside you can see that the L motors are also structural, both axles are designed around them: And here's how the Driveline, Steering and Suspension system are integrated into the model: As mentioned before this is also a convertible which means that the roof can be unfolded and raised: Now for a little of backstory. Originally I tried using PU L motors to make this model a bit more intelligent and capable of holding the wheel suspension positions automacally. Unfortunately PU motors have a very sensitive current protection and were simply not capable of holding the weight of the car even though I'm using shock absorbers to help carry weight. Worth mentioning is also that suspension arms are shorter in the rear to compensate for extra weight. I could have added extra gearing, but that would make the model even bigger and suspension slower. So I took some L motors I had laying around from the Go-Kart project and used them in place of PU ones. Thanks to their shorter size I even gained some additional space and reduced complexity. During testing I decided to double up the BuWizz bricks. I did that for two reasons, first to increase the weight in the back for higher front bounces and secondly to supply the needed power to actuate 4L motor at maximum speed at the same time (each motor draws some 2 Amps when stalled in Ludicrous mode). I hope that's enough details and media for now, I will post photos of the real deal once I get the missing parts and I will of course record a proper video. -
This is an Impala I made trying to recreate with Lego the one that Ice Cube drives on the music video "It Was a Good Day".This MOC had some challenges, making an articulated suspension to simulate several positions and support the height of the car.Also, the green mudguards were a pain in the megablocks to find, it was released only one part in just one set (Marvel Superheroes set).The chrome touch is made with the parts I bought from Chrome Block City.The Ice Cube's bandana, I paint in black one pirate bandana, then I draw by freehand with a Sakura pen and finally put some Tamyia clear gloss varnish. Ice Cube's Impala 64 - Lowrider by Sérgio Batista, no Flickr Ice Cube's Impala 64 by Sérgio Batista, no Flickr Ice Cube's Impala 64 - Lowrider by Sérgio Batista, no Flickr
-
Hi Guys! I finished my new model. I didn't hold on to any real car, but it is similar to the old classic Chevrolet Bell Air / Impala. There's nothing to open, it's just a riding model. Drive / Turn = standard L-Motor / Servo. There is a 1:1 transfer from the L-motor to the differential. photos: FLICKR -
Hi, guys Remote controlled Pickup with Top Gear Rally Car profile Lambo doors, adjustable height of the rear axle (manual) Download for free at lforces.com Happy Easter!
-
Hi guys, has been a while since I visited here, but wanted to try this contest out. I plan to do the Willard Faction (Similar to the buick GNX) from GTA V. (Image below) I've come up with an idea for the hydraulics which allows a significant amount of lift, as well as there to be suspension involved. Here's a potato quality video to show you what I mean. Ignore the ugly yellow wheels, if the project gets far enough i'll BrickLink some! Hope you guys like it! -ender
