General Part Discussion

[msk6003]

2 minutes ago, Lyichir said:

The triple axle connectors on the wings are definitely new

New in orange but not new part.

[SNIPE]

1 hour ago, msk6003 said:

I have picture of all new parts but I don't know when can I upload it.

I like to use imgbb.com because its fast to use and not censored in the UK. They also don't auto-delete images, or if they do its after a while by default

[msk6003]

New

39794 frame 11x7 in reddish brown

64782 panel 5x11 in reddish brown

11954 panel 11x3 curved 10 hole in reddish brown

88323 link tread 5L in reddish brown

[SNIPE]

43857 in orange

2L diameter macaroni technic pieces in trans clear

[msk6003]

1 hour ago, SNIPE said:

43857 in orange

2L diameter macaroni technic pieces in trans clear

First one came on jeep at march and second one is one of recolor of new education sets.

[Ngoc Nguyen]

Hi everyone, this is something messy, exciting, and also worrying at the same time from RacingBrick



Edited Thursday at 05:41 AM by Ngoc Nguyen

[msk6003]

Science new parts

The part sizes are estimates. I didn't have time to measure them.

3.5x16 rack gear plate - dark purple and LBG

16x16 curved rack gear plate - white only

4x4x2 rack gear guide and gear mount - TR.clear only

2.5 and 1.5 2 stage pulley - black only (Last new release of any kind of pulley part which is not wheel is 1993 with micromotor pulley)

Technic brick 2x4 with 4 pinhole and 2 fixed friction pin - white only

Technic brick 6x5x1 with 4x4 cutout and 9 pinhole ㄷ shape - white only

Plate 1x4x2/3 with 1x2 cutout - coral only

[HorcikDesigns]

Curved gear rack with this orientation of teeth? Sounds like some unorthodox (and unorthogonal) teeth geometries were used  to make it work. The train will then need precise positioning while going on that curve, which will probably add some stress and friction...

Looking forward to see how the gear wheels meshes with it under different conditions and loads.

Edited Thursday at 01:49 PM by HorcikDesigns

[Johnny1360]

Those new track pieces are larger than I had originally thought, thanks for the pictures. I wonder if that curve is the same as train track? Looks like excellent monorail track.

[pleegwat]

If I remember correctly train track has a 40 stud radius, which is significantly more than the 15 or 16 stud radius of this curved gear rack.
